The frame holds everything together and takes every crash. A good frame flies cleanly, protects your electronics and is easy to work on. A bad one shakes, cracks and makes every repair a struggle.
Size is set by the props
Frame size is measured diagonally from motor to motor, in millimeters, and it’s matched to prop size.
| Prop size | Typical frame size |
|---|---|
| 3 inch | 120–150 mm |
| 5 inch | 210–230 mm |
| 7 inch | 280–320 mm |
| 10 inch | 400–450 mm |
Geometry: true-X, squashed-X and stretched-X
- True-X: motors form a perfect square. Handling is the same on roll and pitch, which many freestyle pilots like.
- Squashed-X: motors are wider than they are long. Common on freestyle frames; feels stable on roll.
- Stretched-X: longer than wide. Racing and long-range frames use this to keep props out of the camera’s view and improve pitch handling at speed.
- Deadcat: front arms swept outward so props don’t appear in the camera view. Popular for cinematic builds.
Arm thickness and carbon quality
On a 5-inch freestyle frame, 5 mm arms are a good balance of strength and weight; 6 mm is tougher for bashing. Racing frames may use 4–5 mm to save weight.
Carbon quality varies widely. Good carbon is dense with clean, sealed edges. Cheap carbon frays and cracks. Look for:
- Chamfered edges: smooth edges that won’t cut wires or crack.
- Twill or quality unidirectional layups: better strength.
- Replaceable arms: individually bolted arms let you replace just the broken one.
More on durability in crash-resistant frame design.
Stack and camera space
Check before you buy:
- Stack mounting: 30.5×30.5 or 20×20 mm.
- Camera width: 19 mm “micro” or 20 mm cameras, and space for a digital camera if you use one.
- Standoff height: enough room for your stack and wiring.
- Top-mounted or bottom-mounted battery.
Stiffness and vibration
A frame that flexes or resonates feeds vibration into the gyro. Stiff arms, a solid center and tight bolts give a cleaner tune. Loose screws are a very common cause of mysterious oscillations. See vibration damping.
Weight
A 5-inch freestyle frame usually weighs 100–130 g. Lighter frames fly a bit more nimbly but survive less abuse. For a first build, choose durability over grams.
How frame geometry affects flight feel
| Geometry | Feel | Best for |
|---|---|---|
| True-X | Balanced on all axes | Freestyle all-rounders |
| Squashed-X | Stable roll, slightly quicker pitch response | Freestyle |
| Stretched-X | Locked-in at speed | Racing, long range |
| Deadcat | Clean camera view, slight imbalance | Cinematic |
| H-frame | Room for gear, simple layout | Heavy cameras, long range |
Top-mounted vs bottom-mounted battery
- Top mount: the classic freestyle setup. Keeps the battery away from the ground in landings and lets the frame flip easily.
- Bottom mount: lowers the center of gravity. Common on some cinematic and long-range builds. The battery takes more hits on landing.
Frame features that save time later
- Easy access to the stack without removing everything.
- Separate camera cage so a crash doesn’t damage the top plate.
- Antenna mounting points at the rear.
- Strap slots that fit common battery straps.
- Common spare parts easily available.
Weight distribution and balance
Place the battery so the center of gravity sits at the frame’s center. A drone that’s nose- or tail-heavy forces some motors to work harder, which wastes battery and makes the tune less consistent. Check by holding the drone at the center with two fingers: it should balance close to level.
Frame materials beyond carbon
Some small and budget frames use plastic or injection-molded designs. Whoops often use plastic frames that flex on impact. Larger GPS frames may use fiberglass, aluminum arms or folding designs for transport. Each trades stiffness, weight and cost differently.
Our recommendation
For a first 5-inch, pick a reputable true-X or squashed-X freestyle frame with 5–6 mm replaceable arms, 30.5×30.5 stack mounting and room for the camera you plan to use. Shop 5-inch frames
Frequently Asked Questions
What size frame do I need for 5-inch props?
Most 5-inch frames measure 210–230 mm diagonally from motor to motor.
What is the difference between true-X and squashed-X?
In a true-X frame, the motors form a perfect square. In a squashed-X, the motors are spread wider than they are long, which changes how the drone handles on roll and pitch.
How thick should drone frame arms be?
For a 5-inch freestyle frame, 5 mm is a common balance, while 6 mm is tougher for hard bashing. Racing frames often use 4–5 mm.
Why does my drone vibrate even with a new frame?
Loose screws, damaged props, a soft or flexing frame, or a resonance at certain motor speeds. Tighten everything and check blackbox logs.
